Traxxas 6509 TQi 2.4GHz User Manual

owners manualMODELS #6507, #6508, #6509

10 • TQi RADIO SYSTEMSteering and Throttle End PointsThe TQi transmitter allows you to choose the limit of the servo’s travel range (or its “end point

TQi RADIO SYSTEM • 11Real-Time TelemetryWith the installed telemetry sensors, the Traxxas Link dashboard comes to life showing you speed, battery volt

12 • TQi RADIO SYSTEMLED Color / Pattern Name NotesSolid green Normal Driving ModeSlow red (0.5 sec on / 0.5 sec off) Binding See page 8 for more info

TQi RADIO SYSTEM • 13Traxxas Link Model MemoryTraxxas Link Model Memory is an exclusive, patent-pending feature of the TQi transmitter. Each time the

14 • TQi RADIO SYSTEMPress MENU to move through options. Press SET to select an option.Press MENU to move through options. Press SET to select an opti

TQi RADIO SYSTEM • 15Set Multi-Function knob for STEERING SENSITIVITY (Expo)Press/hold MENU green LED blinksPress SET red LED blinksx8Press SET to con

1100 Klein Road, Plano Texas 750741-888-TRAXXASowners manualMODELS #6507, #6508, #6509120130 KC1500-R00“Made for iPod” and “Made for iPhone” mean t

2 • TQi RADIO SYSTEMImportant Radio System Precautions• For maximum range, always point the front of transmitter toward the model.• Do not kink the

TQi RADIO SYSTEM • 3TRANSMITTER AND RECEIVERSteering TrimSteering TrimMulti-Function KnobMulti-Function KnobThrottle TriggerThrottle TriggerThrottle N

4 • TQi RADIO SYSTEMInstalling Transmitter Batteries in the Standard BaseYour TQi transmitter uses 4 AA batteries. The battery compartment is located

TQi RADIO SYSTEM • 5Installing Batteries in the TQi Docking Base (Model #6507 Only)Your TQi transmitter uses 4 AA batteries. The battery compartment i

6 • TQi RADIO SYSTEMModels: All 1/16th Scale Models; E-Revo BE; E-Revo; Revo; Revo 3.3; Raptor; Slash 4X4 Series; Slash Series; Slash VXL; S

TQi RADIO SYSTEM • 7Before installing the TQi radio system in your model, make certain the steering trim knob is centered. After you have installed an

8 • TQi RADIO SYSTEM TQi Binding InstructionsFor proper operation, the transmitter and receiver must be electronically ‘bound.’ This has been done for

TQi RADIO SYSTEM • 9Available Tuning AdjustmentsAll the features described below may also be accessed using the menu and set buttons on the transmitte
